New design aluminum housing IP66 30W 40W 60W led garden light waterproof
GY09 Series LED Garden light
Technical Parameter
| | GY09-15-G | GY09-15-L | GY09-15-D |
| Power(watt) | 30 | 40 | 60 |
| Input Voltage(V) | AC100~240V/50~60Hz |
| PF | ≥0.9 |
| Light Source | Philips-3030 | Philips-3030 | Philips-5050 |
| LED Qty(pcs) | 64 | 64 | 32 |
| LENS Qty(pcs) | 4 | 4 | 4 |
| CCT | 2700K-6500K |
| Lighting Efficiency(lm/w) | 130lm/w |
| CRI | >Ra70 |
| IP/IK Rate | IP66/IK08 |
| THD | <15% |
| Operate Temperature(℃) | -20~+55℃ |
| Product Size(mm) | 323*323*407mm | 398*323*159mm | 323*323*302mm |
| Material | Die-casting aluminum |
| Lifetime Span(H) | 50000H |
| Warranty(years) | 5 years |
| | GY09-110-G | GY09-110-L | GY09-110-D |
| Power(watt) | 80 | 100 | 150 |
| Input Voltage(V) | AC100~240V/50~60Hz |
| PF | ≥0.9 |
| Light Source | Philips-3030 | Philips-3030 | Philips-5050 |
| LED Qty(pcs) | 108 | 144 | 72 |
| LENS Qty(pcs) | 9 | 9 | 9 |
| CCT | 2700K-6500K |
| Lighting Efficiency(lm/w) | 130lm/w |
| CRI | >Ra70 |
| IP/IK Rate | IP66/IK08 |
| THD | <15% |
| Operate Temperature(℃) | -20~+55℃ |
| Product Size(mm) | 485*485*546mm | 485*485*329mm | 485*485*185mm |
| Material | Die-casting aluminum |
| Lifetime Span(H) | 50000H |
| Warranty(years) | 5 years |
Features
IP66 waterproof/dustproof
Aluminum material with good heat dissipation
The lamp post can be adjusted to 15 degrees. It can also be installed vertically
Philips SMD 3030/ 5050/ Ra>70/SDCM<6
100,000 times switching cycle before failure
Total harmonic distortion(THD)<10%
Excellent post light control design
Pass 3G vibration test
Application:
It is mainly applied to branch roads, factories, schools, gardens, various residential communities, and courtyards.
The installation height is 4-10m.
Advantages:
Easy Installation, Low Maintenance,
High efficiency and energy saving
Elegant and modern design with electrostatic spray surface treatment, tool-less, top open, easy for maintenance. Superior aluminum die-casting housing with larger area heat dissipation to achieve excellent dissipation performance.
